| Turbine stirrer: | Device intended for mixing fluids of viscosity up to 5000mPa*s; |
| the system consist of unfolded stirrer and vertical transmission shaft set in the worm transmission sleeve; | |
| Impeller equipped with set of blades inclined approx at an angle of 45° which ensure axial and radial flow of liquids inside the IBC container. Automatically unfoldable; |
|
| Impeller with an external diameter of the blades of approx 350mm and a shaft made of 316TI grade acid-proof steinless steel; | |
| Load-bearing frame + lifting system: | The load-bearing frame made of S235 structural steel, powder painted in a RAL colour selected by the customer; |
| Device equipped with mechanical arm lifting system linked to the turbine stirrer; | |
|
Lifting mechanism using a chain winch without the possibility of the mixer falling down automatically. |
|
| Stirrer motor: | The system is equipped with a 1.1 kW pneumatic motor; |
|
Maximum air demand 1900l/min. |
|
|
Nominal working pressure 0.6 MPa. |
|
|
Rotor speed in the range of 100-300 rpm. |
|
| Contact number: +48 788 870 753 | |
| e-mail: sales@teknomatik.eu |
Product Details
Data sheet
- Maximum viscosity of mixing liquid
- 5000 mPa*s
- Engine power
- 1,1kW
- Stirrer nominal revolutions
- adjustable from 100 - 300 rpm
- Stirrer’s impeller
- ∅500 mm unfoldable, made of the 316Ti stainless steel
- Maximum air demand
- 0,6MPa; 1900l/min
Safety
